Auto Parts Spindle Bearing Sealed Angular Contact Ball Bearing 70, 72, 718, 719 for Machine Tool Sp

Ask Lasest Price
Certification :	ISO9001, CE, SGS, 16949
Brand Name :	CAEC
Model Number :	B7007/B7008/B7009C-2RZHQ1P4A
Price :	USD 1 for one set
Payment Terms :	L/C, T/T
Supply Ability :	1000000 PCS/Year
Delivery Time :	10-15 days

Add to Cart

Product Details
Company Profile

Auto Parts Spindle Bearing Sealed Angular Contact Ball Bearing 70, 72, 718, 719 for Machine Tool Sp

The precision angular contact ball bearings for spindles, have four size series,718,719,70 and 72. With the same inner diameter, the outer diameters and the widths of 718,719,70 and 72 series increase in turn.

CAEC precision angular contact ball bearing with 15 ° (C) and 25 ° (AC) contact angles. As for the angular contact ball bearings, the bigger the contact angle is, the greater the axial load capacity is, but the lower the limited speed of bearings becomes. Therefore ,the spindle, with high speed and small axial load ,should adopt the 15 ° angular contact ball bearings,whereas the 25 ° angular contact ball bearing should be adopted.

CAEC precision angular contact ball bearings with high-speed angular contact bearings (standard series), super-speed angular contact ball bearings, high-speed sealed angular contact ball bearings and high-speed spindle bearings.

Types and performances of angular contact ball bearing :

CAEC precision angular contact ball bearings with high-speed angular contact bearings (standard series), super-speed angular contact ball bearings, high-speed sealed angular contact ball bearings and high-speed spindle bearings.

Auto Parts Spindle Bearing Sealed Angular Contact Ball Bearing 70, 72, 718, 719 for Machine Tool Sp

Dimension table of angular contact ball bearing:

H70/H719 series Super high speed angular contact ball bearing
Principal dimensions					α= 15°				α= 25°				ZYS Bearing Designations
					Basic load ratings		Limiting speed		Basic load ratings		Limiting speed
d	D	B	rsmin	rIsmin	Cr	Cor	Grease	Oil	Cr	Cor	Grease	Oil
mm≈					KN		r/min
10	22	6	0.30	0.10	2.1	0.9	85000	140000	2.0	0.9	75000	120000	H71900
10	22	6	0.30	0.10	2.1	0.9	95000	160000	2.0	0.9	85000	140000	H71900/HQ1
10	26	8	0.30	0.15	3.4	1.5	80000	130000	3.3	1.4	67000	110000	H7000
10	26	8	0.30	0.15	3.4	1.5	90000	150000	3.3	1.4	80000	130000	H7000/HQ1
12	24	6	0.30	0.10	2.2	1.1	80000	130000	2.1	1.1	70000	110000	H71901
12	24	6	0.30	0.10	2.2	1.1	90000	150000	2.1	1.1	80000	130000	H71901/HQ1
12	28	8	0.30	0.15	3.8	1.7	70000	110000	3.6	1.6	60000	90000	H7001
12	28	8	0.30	0.15	3.8	1.7	80000	130000	3.6	1.6	70000	110000	H7001/HQ1
15	28	7	0.30	0.10	3.2	1.7	70000	110000	3.1	1.6	60000	90000	H71902
15	28	7	0.30	0.10	3.2	1.7	80000	130000	3.1	1.6	70000	110000	H71902/HQ1
15	32	9	0.30	0.15	4.4	2.2	67000	100000	4.2	2.1	56000	85000	H7002
15	32	9	0.30	0.15	4.4	2.2	75000	120000	4.2	2.1	67000	100000	H7002/HQ1
17	30	7	0.30	0.10	3.3	1.8	67000	100000	3.2	1.7	56000	85000	H71903
17	30	7	0.30	0.10	3.3	1.8	75000	120000	3.2	1.7	63000	95000	H71903/HQ1
17	35	10	0.30	0.15	5.2	2.5	56000	85000	5.0	2.4	50000	75000	H7003
17	35	10	0.30	0.15	5.2	2.5	63000	95000	5.0	2.4	60000	90000	H7003/HQ1
20	37	9	0.30	0.15	5.0	2.9	53000	80000	4.8	2.7	45000	67000	H71904
20	37	9	0.30	0.15	5.0	2.9	63000	95000	4.8	2.7	53000	80000	H71904/HQ1
20	42	12	0.60	0.15	7.4	3.9	50000	75000	7.0	3.8	43000	63000	H7004
20	42	12	0.60	0.15	7.4	3.9	60000	90000	7.0	3.8	48000	70000	H7004/HQ1
25	42	9	0.30	0.15	5.2	3.4	48000	70000	4.9	3.3	40000	60000	H71905
25	42	9	0.30	0.15	5.2	3.4	53000	80000	4.9	3.3	45000	67000	H71905/HQ1
25	47	12	0.60	0.15	8.4	4.8	43000	63000	8.0	4.6	36000	53000	H7005
25	47	12	0.60	0.15	8.4	4.8	48000	70000	8.0	4.6	43000	63000	H7005/HQ1
30	47	9	0.30	0.15	5.8	3.8	43000	63000	5.4	3.6	36000	53000	H71906
30	47	9	0.30	0.15	5.8	3.8	48000	70000	5.4	3.6	40000	60000	H71906/HQ1
30	55	13	1.00	0.30	9.5	6.2	38000	56000	9.0	5.9	34000	50000	H7006
30	55	13	1.00	0.30	9.5	6.2	45000	67000	9.0	5.9	38000	56000	H7006/HQ1
35	55	10	0.60	0.15	7.7	5.4	36000	53000	7.4	5.1	30000	45000	H71907
35	55	10	0.60	0.15	7.7	5.4	40000	60000	7.4	5.1	34000	50000	H71907/HQ1
35	62	14	1.00	0.30	11.2	7.9	34000	50000	10.7	7.5	30000	45000	H7007
35	62	14	1.00	0.30	11.2	7.9	38000	56000	10.7	7.5	34000	50000	H7007/HQ1
40	62	12	0.60	0.15	9.8	7.0	30000	45000	9.3	6.6	26000	40000	H71908
40	62	12	0.60	0.15	9.8	7.0	34000	50000	9.3	6.6	28000	43000	H71908/HQ1
40	68	15	1.00	0.30	12.5	9.1	28000	43000	11.1	8.6	24000	38000	H7008
40	68	15	1.00	0.30	12.5	9.1	34000	50000	11.1	8.6	28000	43000	H7008/HQ1
45	68	12	0.60	0.15	10.3	7.7	26000	40000	9.7	7.3	22000	36000	H71909
45	68	12	0.60	0.15	10.3	7.7	28000	43000	9.7	7.3	26000	40000	H71909/HQ1
45	75	16	1.00	0.30	13.1	10.2	24000	38000	12.5	9.7	22000	36000	H7009
45	75	16	1.00	0.30	13.1	10.2	28000	43000	12.5	9.7	26000	40000	H7009/HQ1
50	72	12	0.60	0.15	13.2	10.0	22000	36000	12.5	9.5	19000	32000	H71910
50	72	12	0.60	0.15	13.2	10.0	26000	40000	12.5	9.5	22000	36000	H71910/HQ1
50	80	16	1.00	0.30	15.4	12.0	20000	34000	14.7	11.4	18000	30000	H7010
50	80	16	1.00	0.30	15.4	12.0	24000	38000	14.7	11.4	20000	34000	H7010/HQ1
55	80	13	1.00	0.30	16.0	12.6	19000	32000	15.0	11.9	16000	26000	H71911
55	80	13	1.00	0.30	16.0	12.6	22000	36000	15.0	11.9	19000	32000	H71911/HQ1
55	90	18	1.10	0.60	17.0	14.5	19000	32000	16.0	13.7	17000	28000	H7011
55	90	18	1.10	0.60	17.0	14.5	22000	36000	16.0	13.7	19000	32000	H7011/HQ1
60	85	13	1.00	0.30	16.6	13.8	18000	30000	15.7	13.1	15000	24000	H71912
60	85	13	1.00	0.30	16.6	13.8	20000	34000	15.7	13.1	18000	30000	H71912/HQ1
60	95	18	1.10	0.60	17.0	15.3	18000	30000	16.2	14.4	15000	24000	H7012
60	95	18	1.10	0.60	17.0	15.3	20000	34000	16.2	14.4	18000	30000	H7012/HQ1
65	90	13	1.00	0.30	16.8	14.5	17000	28000	16.0	13.7	15000	24000	H71913
65	90	13	1.00	0.30	16.8	14.5	19000	32000	16.0	13.7	17000	28000	H71913/HQ1
65	100	18	1.10	0.60	20.2	18.6	16000	26000	19.0	17.6	13000	20000	H7013
65	100	18	1.10	0.60	20.2	18.6	19000	32000	19.0	17.6	15000	24000	H7013/HQ1
70	100	16	1.00	0.30	20.9	17.8	16000	26000	19.7	16.9	13000	20000	H71914
70	100	16	1.00	0.30	20.9	17.8	18000	30000	19.7	16.9	15000	24000	H71914/HQ1
70	110	20	1.10	0.60	24.1	21.4	15000	24000	22.6	20.1	13000	20000	H7014
70	110	20	1.10	0.60	24.1	21.4	18000	30000	22.6	20.1	15000	24000	H7014/HQ1
75	105	16	1.00	0.30	21.7	19.3	15000	24000	20.5	18.2	13000	20000	H71915
75	105	16	1.00	0.30	21.7	19.3	17000	28000	20.5	18.2	15000	24000	H71915/HQ1
75	115	20	1.10	0.60	26.2	25.5	14000	22000	24.7	24.2	12000	19000	H7015
75	115	20	1.10	0.60	26.2	25.5	16000	26000	24.7	24.2	14000	22000	H7015/HQ1
80	110	16	1.00	0.30	22.4	20.8	14000	22000	21.2	19.6	12000	19000	H71916
80	110	16	1.00	0.30	22.4	20.8	16000	26000	21.2	19.6	14000	22000	H71916/HQ1
80	125	22	1.10	0.60	34.2	32.7	13000	20000	32.3	31.0	11000	18000	H7016
80	125	22	1.10	0.60	34.2	32.7	15000	24000	32.3	31.0	13000	20000	H7016/HQ1
85	120	18	1.10	0.60	26.1	24.2	13000	20000	24.7	22.9	11000	18000	H71917
85	120	18	1.10	0.60	26.1	24.2	15000	24000	24.7	22.9	13000	20000	H71917/HQ1
85	130	22	1.10	0.60	35.0	35.2	12000	19000	33.0	33.4	10000	17000	H7017
85	130	22	1.10	0.60	35.0	35.2	14000	22000	33.0	33.4	12000	19000	H7017/HQ1
90	125	18	1.10	0.60	27.0	26.0	13000	20000	25.5	24.6	11000	18000	H71918
90	125	18	1.10	0.60	27.0	26.0	15000	24000	25.5	24.6	13000	20000	H71918/HQ1
90	140	24	1.50	0.60	36.4	38.1	11000	18000	34.3	36.1	9500	16000	H7018
90	140	24	1.50	0.60	36.4	38.1	13000	20000	34.3	36.1	11000	18000	H7018/HQ1
95	130	18	1.10	0.60	27.3	26.9	12000	19000	25.8	25.4	11000	18000	H71919
95	130	18	1.10	0.60	27.3	26.9	14000	22000	25.8	25.4	13000	20000	H71919/HQ1
95	145	24	1.50	0.60	44.4	45.2	10000	17000	41.9	42.9	8500	14000	H7019
95	145	24	1.50	0.60	44.4	45.2	12000	19000	41.9	42.9	10000	17000	H7019/HQ1
100	140	20	1.10	0.60	40.1	37.6	11000	18000	37.9	35.5	9000	15000	H71920
100	140	20	1.10	0.60	40.1	37.6	13000	20000	37.9	35.5	11000	18000	H71920/HQ1
100	150	24	1.50	0.60	45.4	48.1	10000	17000	42.7	44.7	8500	14000	H7020
100	150	24	1.50	0.60	45.4	48.1	12000	19000	42.7	44.7	10000	17000	H7020/HQ1
105	145	20	1.10	0.60	40.7	39.1	10000	17000	38.4	36.9	8500	14000	H71921
105	145	20	1.10	0.60	40.7	39.1	12000	19000	38.4	36.9	10000	17000	H71921/HQ1
105	160	26	2.00	1.00	46.1	49.2	9500	16000	43.3	46.6	8000	13000	H7021
105	160	26	2.00	1.00	46.1	49.2	11000	18000	43.3	46.6	9000	15000	H7021/HQ1
110	150	20	1.10	0.60	41.3	40.5	9000	15000	39.0	38.3	7500	12000	H71922
110	150	20	1.10	0.60	41.3	40.5	11000	18000	39.0	38.3	9500	16000	H71922/HQ1
110	170	28	2.00	1.00	47.9	53.9	9500	16000	45.1	51.1	8000	13000	H7022
110	170	28	2.00	1.00	47.9	53.9	11000	18000	45.1	51.1	9000	15000	H7022/HQ1
120	165	22	1.10	0.60	43.1	44.9	8500	14000	40.7	42.4	7500	12000	H71924
120	165	22	1.10	0.60	43.1	44.9	10000	17000	40.7	42.4	9000	15000	H71924/HQ1
120	180	28	2.00	1.00	58.3	64.9	8500	14000	54.8	61.5	7500	12000	H7024
120	180	28	2.00	1.00	58.3	64.9	10000	17000	54.8	61.5	9000	15000	H7024/HQ1
130	180	24	1.50	0.60	53.1	56.6	8000	13000	50.1	53.4	7500	12000	H71926
130	180	24	1.50	0.60	53.1	56.6	9000	15000	50.1	53.4	8500	14000	H71926/HQ1
130	200	33	2.00	1.00	58.6	66.8	8000	13000	55.1	63.2	7000	11000	H7026
130	200	33	2.00	1.00	58.6	66.8	9000	15000	55.1	63.2	8000	13000	H7026/HQ1
140	190	24	1.50	0.60	53.7	59.1	7000	11000	50.7	55.8	6700	10000	H71928
140	190	24	1.50	0.60	53.7	59.1	8000	13000	50.7	55.8	7500	12000	H71928/HQ1
140	210	33	2.00	1.00	60.7	72.5	7500	12000	57.1	68.7	6700	10000	H7028
140	210	33	2.00	1.00	60.7	72.5	8500	14000	57.1	68.7	7500	12000	H7028/HQ1
150	210	28	2.00	1.00	65.2	72.8	6700	10000	61.5	68.7	6000	9000	H71930
150	210	28	2.00	1.00	65.2	72.8	7500	12000	61.5	68.7	7000	11000	H71930/HQ1
150	225	35	2.10	1.10	74.9	88.5	6700	10000	70.5	83.8	6300	9500	H7030
150	225	35	2.10	1.10	74.9	88.5	7500	12000	70.5	83.8	7000	11000	H7030/HQ1
160	220	28	2.00	1.00	66.0	75.8	6000	9000	62.3	71.6	5600	8500	H71932
160	220	28	2.00	1.00	66.0	75.8	7000	11000	62.3	71.6	6700	10000	H71932/HQ1
160	240	38	2.10	1.10	76.2	94.5	6000	9000	71.6	89.5	5600	8500	H7032
160	240	38	2.10	1.10	76.2	94.5	6700	10000	71.6	89.5	6300	9500	H7032/HQ1
170	230	28	2.00	1.00	66.7	78.7	5600	8500	63.0	74.3	5000	7500	H71934
170	230	28	2.00	1.00	66.7	78.7	6700	10000	63.0	74.3	6000	9000	H71934/HQ1
170	260	42	2.10	1.10	78.1	100.6	5600	8500	73.4	95.2	5000	7500	H7034
170	260	42	2.10	1.10	78.1	100.6	6300	9500	73.4	95.2	5600	8500	H7034/HQ1
180	250	33	2.00	1.00	79.6	95.0	5000	7500	75.2	89.7	4800	7000	H71936
180	250	33	2.00	1.00	79.6	95.0	6000	9000	75.2	89.7	5600	8500	H71936/HQ1
180	280	46	2.10	1.10	79.8	106.7	5300	8000	75.0	101.0	4800	7000	H7036
180	280	46	2.10	1.10	79.8	106.7	6000	9000	75.0	101.0	5300	8000	H7036/HQ1
190	260	33	2.00	1.00	80.6	98.6	4800	7000	76.1	93.1	4300	6300	H71938
190	260	33	2.00	1.00	80.6	98.6	5600	8500	76.1	93.1	5000	7500	H71938/HQ1
190	290	46	2.10	1.10	95.3	124.6	4800	7000	89.7	117.9	4300	6300	H7038
190	290	46	2.10	1.10	95.3	124.6	5300	8000	89.7	117.9	4800	7000	H7038/HQ1
200	280	38	2.00	1.00	82.8	105.4	4500	6700	78.2	99.5	4000	6000	H71940
200	280	38	2.00	1.00	82.8	105.4	5000	7500	78.2	99.5	4500	6700	H71940/HQ1
200	310	51	2.10	1.10	96.5	132.0	4500	6700	90.8	124.9	4000	6000	H7040
200	310	51	2.10	1.10	96.5	132.0	5000	7500	90.8	124.9	4500	6700	H7040/HQ1
220	300	38	2.00	1.00	96.9	125.4	4300	6300	91.5	118.4	3800	5600	H71944
220	300	38	2.00	1.00	96.9	125.4	5000	7500	91.5	118.4	4300	6300	H71944/HQ1
220	340	56	3.00	1.10	113.9	156.5	4000	6000	107.2	148.1	3800	5600	H7044
220	340	56	3.00	1.10	113.9	156.5	4500	6700	107.2	148.1	4000	6000	H7044/HQ1

Performance characteristics of spindle bearing: Ultra high speed, high stiffness, high carrying capacity, good running performance, easy mounting of universally matchable bearings, suitable for oil and gas lubrication or injection lubrication.

Applications of spindle bearing: CAEC super high speed single row angular contact ball bearings might be used in the fields of machine tools, textiles, automobiles, railways, metallurgy, chemicals, electronics, Industrial pumps, Compressors, Material Handling, Electric motors.

Product features of angular contact ball bearing:

1. High-quality bearing materials: CAEC adopts ultra-clean steel, high purity high-carbon chromium bearing steel GCr15 from a well-known domestic manufacturer, which can extend the life of the bearing by 80%.

2. High quality bearing rolling elements: The bearing balls provided by CAEC have good product performance to ensure the optimal bearing configuration and smooth operation at high speed and quiet. CAEC has a complete process production line, from powder ultrasonic pre-dispersion, mixture mixing, spray drying granulation, near-net-size molding, cold isostatic pressing, GPS-HIP combined sintering process, high-precision grinding and processing, total quality inspection to packaging. CAEC has a comprehensive quality control system, quality identification of raw materials and auxiliary materials, quality control of mixed materials, quality control of pressing and sintering, and quality control of finished products.

3. More suitable bearing cage: CAEC mostly adopts bakelite cage, which can more effectively reduce the friction between metal and bearing balls and extend the life of the bearing. CAEC can also choose more suitable bearing cage materials according to customer requirements and bearing applications.

4. Advanced lubrication technology: CAEC uses high performance grease and advanced lubrication technology to extend bearing life and improve bearing performance.

5. Ultra finished raceways:CAEC uses special honing to minimize noise, improve lubricant dispersion and increase bearing life.

6. Contact angle: CAEC ultra high speed precision bearings usually use 15°and 25° contact angles.

7. Accuracy grade: CAEC can offer the high precision angular contact ball bearings with P2, P4A, P4 grade.

CAEC Precision Bearing Quality Control and Assurance:

Austrian AICHELIN heat treatment equipment and long-life heat treatment process provide a strong guarantee for the continuous and reliable operation of bearings.
Auto Parts Spindle Bearing Sealed Angular Contact Ball Bearing 70, 72, 718, 719 for Machine Tool Sp

FAQ:

Q: Are you trading company or manufacturer?
A: CAEC is bearing manufacturer, the only first-class comprehensive research institute in China bearing industry.

Q: How do you control quality of bearing?
A: CAEC has established quality control systems for each kind of bearing and spindle. All products and services passed ISO9001-2008 Quality Certificate.

Q: What is the MOQ?
A: It depends on the bearing type. You can send inquiry or send e-mail for more information.

Q: How about the package?
A: Industrial packing in general condition (Plastic tube+ carton+ pallet). Accept design package when OEM.

Q: How long is the delivery time?
A: It will take about 10 to 40 days, depends on the model and quantity.

Q: How about the shipping?
A: We can arrange the shipment or you may have the forwarder.

Q: Is sample avaiable?
A: Yes, sample order is acceptable.

Q: Can we use our own LOGO or design on bearings?
A: Yes. OEM is acceptable. We can design the bearing with your requirements and use your own LOGO and package design.

Auto Parts Spindle Bearing Sealed Angular Contact Ball Bearing 70, 72, 718, 719 for Machine Tool Sp

Auto Parts Spindle Bearing Sealed Angular Contact Ball Bearing 70, 72, 718, 719 for Machine Tool Sp

Inquiry Cart 0

Send your message to this supplier


*From:	Your email address is incorrect!
*To:	China Abrasives Industry Hainan Corporation
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Explore more Roller Ball Bearing products from this supplier

Find Similar Products By Category:

Minerals & Metallurgy

Hot Searches:
